Infrared Elevator Light Curtain Lift Door Detector Elevator Parts

Infrared Elevator Light Curtain Lift Door Detector Elevator Parts

Package Size228.00cm * 28.00cm * 17.00cm Package Gross Weight4.200kg Infrared Elevator Light Curtain Lift Door Detector
SHARE
Send inquiry

Description

Basic Info.
Model NO. SN-GM2-Z/09156P
Type Elevator Door System
Suitable for Elevator
Load Capacity 1000kg
Persons 11-20
Speed <1.0m/s
Drive Mode Manual
Control Type Microcomputer Frequency Control
Lift Mechanism Telescoping Lift
Use of Occasions Public Traffic
Guide Rail Hollow Guide
Thickness 9mm
Speciality for Center Opening Door
Voltage 12-24V DC/ 85-300V AC
Beam 156
Length 1960mm
Certificate Ce
Transport Package Round Box
Specification CE, ISO9001, CCC
Trademark SUNNY
Origin Shanghai China
Production Capacity 10000PCS/Month
Packaging & Delivery
Package Size228.00cm * 28.00cm * 17.00cm Package Gross Weight4.200kg
Product Description

Infrared Elevator Light Curtain Lift Door Detector Elevator Parts

Part number: SN-GM2-Z/09192P Middle-open Light Curtain P series

Specification
FAQ

Q1:Is there free samples?

A:Yes,we could offer free sample if the unit price is less than 10usd, please contact me.

Q2:Customized logo on the elevator parts?

A:Yes,OEM and ODM are available for us.

But you should send us the Trademark authorization letter, there is min order quantity.

Q3:Get the after-service?

A:We will send you the spare parts by free if the problems caused by us.

Q4 :Inspection procedures for elevator parts?

A:100% self-inspection before packing.

Q5:Mix the 20ft container?

A: Yes,let us know your requirments please

Q6: Visit to your company before the order?

A:Sure,welcome to visit us. Our location is near by Shanghai Hongqiao airport.

Q7: By paypal and western union or cash or CNY?

A: Yes,please contact us for detail.

Q8: Delivery time of the parts?

A:Depend on the products your asked, please contact us for detail.

Q9:How to place order?

A:1.let us know your requirment; 2 confirm the detail we will make proforma invoice for you; 3.send us payment and bankslip,or you could pay we will release work order accordingly.4.We will send goods to you with the shipping metherd we confirmed.

Our factory
TECHNICAL SPECIFICATIONS
Model
 SN-GM1-Z/09192P
Number of Diode
 64
Distance Between Diodes
 42mm middle/ 55mm side
Maximum Beams
 156
Minimum Beams
 156
Highest Beam
 1800±50mm
Lowest Beam
 17±5mm
Size
 30(width) * 09 (thickness) * 1980mm (height)
Detecting Distance
 0~~~~4,000mm + 500mm (standard), 20,000mm for custmization
Vertical displacement at 0 mm
 ≤ ±20mm
Horizontal displacement at 0 mm
 ≤ ±10mm
Angular displacement at 0 mm
 ≤ ± 8°
Cable reliablity
 3C passed three-core flexibility wire, tensile resistance < 15N, endure 1,000,000 time twist, length 4.5M ±10%
Light immunity
 ≥ 100,000 lux
Immune to Sun Light and Refelection
 Yes
EMC Compliance
 Emission to EN 12015 and Immunity to EN 12016
CE Compliances
 YES
UL Compliances
 Yes! UL 508,17th Edition, Jan,1999. File NO. E230770
Operating temperature range
 -25----+65
IP Rating
 IP63detector IP65 controllerbox
Vibration Test
 5-55HZ, amplitutde 0.19mm, 20min
Response Time (NPN or PNP)
 NO
Response Time ( Relay )
 ≤ 80 ms
Timeout function
 30 ± 5 s
Power Consumption
 ≤ 7.5 VA
Signal Output
 Relay Output
Power Indicator
 YES, LED Light
Status Indicator
 YES, LED Light
Buzzer in Receiver
 active if anything block the light beam for continuous 25 second
Voltage Tolerance
 AC 85~240V 60/50HZ


Why choose us?
Shanghai Sunny Elevator Co., Ltd, founded in 1992, is a 32-year professional manufacturer specializing in designing and producting Opto-Electro-Mechanical products.
Sunny Elevator has started import and export since 2012.
We have experience for exporting all kinds of elevator & elevator parts to 80 countries all over the world.

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won't break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
